Features:
1. Relay/microprocessor control(CPU)
2. Wide range voltage regulation
3. Technology: classis series, EI transformer or toroidal transformer, relay type
Specification:
Control: Relay Control
Phase: Single Phase
Input voltage:140-260V
Input frequency:50/60Hz
Output voltage:220V AC
Output precision:220V±3%, 110V±6%
Protection functions: over voltage, overload, over temperature, low voltage, time delay
Time delay:3’s short time,180’s long time
Efficiency:>90%
Transformer:copper/copper with aluminum
Display:LCD display
Operating temperature:0~40℃
Storage temperature:-15℃~45℃
Operating Relative humidity:10%RH~102%RH
